LE MINI SENSOR

Integrated temperature probe
Thermoswitch for device protection
Heating element protection
Analogue output (passive) 4 – 20 mA

The world’s smallest air heater with an integrated temperature probe. Especially suited for applications in which heat is concentrated to a point. It is simple to incorporate into the tightest spaces. LE MINI operates with compressed air at a pressure of 200 kPa. Model versions are available with or without an integrated sensor.

Specification

		LE MINI SENSOR - 230 V / 400 W	LE MINI SENSOR - 230 V / 800 W
Article No.:		117.370	117.369
Attribute	Unit	Value	Value
Voltage	V~	230	230
Power	W	400	800
Max. air outlet temperature	°C	600	750
Min. air volume (20°C)	l/min	10	10
Max. ambient temperature	°C	60	60
Max. supply air pressure	kPa	200	200
Weight	kg	0,12	0,15
Weight Converter	kg	0,19	0,19
Size (L × ∅)	mm	200 × 25	308 × 25
Conformity mark
Approval mark
Protection class II
